ODGOVARA ZA:
IMT/IMR
IMT 577
Massey Ferguson
Serija: 100
165, 168, 168F, 168S, 174, 174C, 174F, 174S, 174V, 175, 175S, 178, 184, 184F, 184S, 185, 188, 194, 194C, 194F, 194S,
Serija: 1000, 1004T, 1007
Serija: 200
255 (USA), 265, 273 (LD22573, LD22813 ), 274 (LD31174, LD31175 ), 274C (LD31174, LD31175 ), 274CF (LD22573, LD22813 ), 274S (LD31174, LD31175 ), 274SK (LD22573, LD22813 ), 275, 275E, 283 (LD22574, LD22756 ), 284 (LD31172, LD31173 ), 284S (LD22574, LD22756 ), 285, 290, 290E, 293 (LF31176, LF31177 ), 294 (LF31176, LF31177 ), 294C (LF31176, LF31177 ), 294S (LF22575, LF22762 ),
Serija: 200 (Brasil - South Africa) 265,
Serija: 2200, 2230,
Serija: 300
362, 362N, 365, 367CF, 372N, 373, 373LX, 373S, 374AP, 374AP(X), 374AQ, 374F, 374FP, 374FP(X), 374FQ, 374GE, 374GE(X), 374H, 374S, 374SP, 374SP(X), 374SQ, 374V, 374VQ, 375, 375E, 376C, 377, 382N, 383, 383LX, 383S, 384AP, 384AP(X), 384AQ, 384F, 384FP, 384FP(X), 384FQ, 384GE, 384GE(X), 384S, 384SP, 384SP(X), 384SQ, 384V, 384VQ, 387, 390, 390E, 390T, 393, 393LX, 393S, 393TLX, 394AP, 394AP(X), 394AQ, 394C, 394F, 394FP, 394FP(X), 394FQ, 394GE, 394GE(X), 394H, 394S, 394SP, 394SP(X), 394SQ, 394TAQ, 396C, 396CT, 397, 397T, 398,
Serija: 3000, 3050, 3055, 3060, 3065, 3065S, 3070, 3075,
Serija: 3200-3300, 3220AP(X), 3220FP(X), 3220GE(X), 3220SP(X), 3225AP(X), 3225FP(X), 3225GE(X), 3225SP(X), 3235AP(X), 3235FP(X), 3235GE(X), 3235SP(X), 3330, 3330F/FE, 3330GE, 3330S, 3330V, 3340, 3350, 3350F/FE, 3350GE, 3350S, 3355, 3355F/FE, 3355GE, 3355S,
Serija: 4200, 4225, 4225HV, 4235, 4235 (USA), 4235HV, 4235HV (USA), 4240, 4245, 4245HV, 4255, 4255HV, 4265,
Serija: 4300, 4325, 4325HV, 4335, 4335HV, 4345, 4345HV, 4355, 4355HV, 4365,
Serija: 500, 590,
Serija: 5200 (Brasil) 5275, 5285, 5290
Serija: 5300 (Brasil) 5300, 5310
Serija: 600, 675 (LD31110 ), 690, 698T,
Serija: 6100, 6110, 6120, 6130, 6140, 6150,
Serija: 6200, 6235, 6235HV, 6245, 6245HV, 6255, 6255HV, 6265,
Industrial tractor
Serija:
20, 30D, 3303, 3305, 50, 50B, 50B MKII, 50C, 50D, 50E, 50EX, 50H (LD31179 ), 50H-S, 50H-T, 50HX, 50HX-S, 50HX-T, 60, 60H, 60H-S, 60HX, 60HX-T,
Combine-harvester
Serija:
10 Plot, 16, 16 Plot, 186, 187, 206, 20XP, 24, 240, 307, 330, 430, 440, 487, 506, 8 Plot, 99,
Telescopic loader
Serija:
24T, 8925, 8925T, 8926, 8926T, 8937, 8937T, 8939, 8939T,
Tip motora:
A4.236 - Maxion Intl. Brasil
A4.236 - Perkins
1004.42 - Perkins
1004.40 - Perkins
A4.248 - Perkins
1004.4T - Perkins
1004.4 - Perkins
AT4.236 - Perkins
1004.40T - Perkins
A4.212 - Perkins
A4.41 - Perkins
D39T - Volvo-BM
DIMENZIJE:
I SPC + 0,25 mm
Prečnik nosača min: 63,225 mm
Prečnik nosača max: 63,237 mm
Kućište min: 67,208 mm
Otvor kućišta max: 67,221 mm
Nosivost gornje polovine: 31.880 mm
Nosivost donje polovine. 31.880 mm
Debljina zida: 1.966 mm
Kućište min.:
80.416 mm
Otvor kućišta max.:
80.441 mm
